NEC Jubilee/Economatics Computer Interface

Home > Browse Our Collection > Peripherals > Learning Computers > NEC Jubilee/Economatics Computer Interface

This expansion board connects to the BBC Micro's user and analogue ports. It appears to be for use in an electronics lab or classroom environment. It provides the following features:

Two tactile button inputs
Eight DIP switch inputs
LED display of tactile/DIP switch states
Three analogue op-amps
One inverting schmitt trigger
Motor, with slotted disc interrupting an opto-isolator input
Connector for microphone input
Child board with three red, three green, and two amber LEDs. Connector is amrked "traffic light socket".
Off-board connectors for digital input/outputs and four analogue inputs.

While we have no documentation for this item, "NEC" is almost certainly not the PC manufacturer. Economatics were a UK company that supplied input/output control boxes and 'turtle' robots for Acorn (and later PC) computers.

Date : Unknown

Manufacturer : Economatics

Physical Description : Interface board LED board Cable

This exhibit has a reference ID of CH44355. Please quote this reference ID in any communication with the Centre for Computing History.

Scan of Document: NEC Jubilee/Economatics Computer Interface
