Intel A80386DX-20 32-bit Microprocessor

 Home > Browse Our Collection > Peripherals > Microprocessors > Intel A80386DX-20 32-bit Microprocessor


The Intel 80386, also known as the i386, or just 386, was a 32-bit microprocessor introduced by Intel in 1985. The first versions had 275,000 transistors and were used as the central processing unit (CPU) of many personal computers and workstations. As the original implementation of the 32-bit extensions to the 8086 architecture, the 80386 instruction set, programming model, and binary encodings are still the common denominator for all 32-bit x86 processors. This is termed x86, IA-32, or the i386-architecture, depending on context.

The 80386 could correctly execute most code intended for earlier 16-bit x86 processors such as the 80286; following the same tradition, modern 64-bit x86 processors are able to run most programs written for older chips, all the way back to the original 16-bit 8086 of 1978. Over the years, successively newer implementations of the same architecture have become several hundreds of times faster than the original 80386 (and thousands of times faster than the 8086). A 33 MHz 80386 was reportedly measured to operate at about 11.4 MIPS.

The 80386 was launched in October 1985, and full-function chips were first delivered in 1986. Mainboards for 80386-based computer systems were at first expensive to buy, but prices were rationalized upon the 80386's mainstream adoption. The first personal computer to make use of the 80386 was designed and manufactured by Compaq.

In May 2006, Intel announced that production of the 80386 would cease at the end of September 2007. Although it has long been obsolete as a personal computer CPU, Intel and others had continued to manufacture the chip for embedded systems. Embedded systems that utilise a 80386 or one of its derivatives are widely used in aerospace technology.

Date : 1985

Manufacturer : Intel

Format : Chip

Physical Description : Processor chip

This exhibit has a reference ID of CH42401. Please quote this reference ID in any communication with the Centre for Computing History.


Scan of Document: Intel A80386DX-20 32-bit Microprocessor

Click on the Image For Detail
