ARM3/FPU - A540 Prototype CPU Card

 Home > Browse Our Collection > Computers > Acorn Computers > Acorn Archimedes Peripherals > ARM3/FPU - A540 Prototype CPU Card


20MHz ARM3 Prototype CPU card for A540.

Uses the same Western Electric WE32206 FP unit with the Acorn custom bridge chip as the Archimedes ARM2 podule, but this ARM 3 has the pins/PCB wiring which a normal ARM 3 board doesn't.

0186,100 Issue B
VL86C020-PSFCC Proto
Acorn FPPC
WE32206

Rescued from a skip when Acorn closed down.

Date : Unknown

Manufacturer : Acorn Computers Ltd

Physical Description : board

This exhibit has a reference ID of CH33923. Please quote this reference ID in any communication with the Centre for Computing History.


Scan of Document: ARM3/FPU - A540 Prototype CPU Card

Click on the Image For Detail
