The Power Macintosh 5000 series is a series of all-in-one (meaning the cases feature an integrated monitor) personal computers that are a part of Apple Computer's Macintosh LC, Power Macintosh and Macintosh Performa series of Macintosh computers.

5300/100 introduced 1995.08.28
requires System 7.5.1 through 9.1
CPU: 100 or 120 MHz PPC 603e
Bus: 40 MHz
ROM: 4 MB
RAM: 16 MB, expandable using one or two 4, 8, 16, or 32 MB 80ns 72-pin SIMMs
VRAM: not expandable
Video: thousands of colors at 640 x 480, 256 at 832 x 624

Microphone: standard 3.5mm minijack, compatible with line-level input including Apple's PlainTalk microphone

ADB: 1 port for keyboard and mouse
DIN-8 serial ports on back of computer (modem port disabled when comm slot modem present; printer port disabled when comm slot ethernet card present)
SCSI: DB-25 connector on back of computer
Ethernet: AAUI connector on back of computer, requires AAUI adapter
One PDS slot (NuBus adapter available)

Our machine is a Model M3046 and is complete with all the original packaging and box and was very kindly donated by Heinz Backmann.

Manufacturer: Apple
Date: 1995

This exhibit has a reference ID of CH24756. Please quote this reference ID in any communication with the Centre for Computing History.
