Computer-aided Design

 Home > Browse Our Collection > Software > Acorn > BBC Micro Software > Five Ways Software > Computer-aided Design


This package introduces pupils to computer-aided design and provides some insight into the importance of computers in modern industry. The user can draw on the screen any shape that is symmetrical abouta single axis (e.g. a wine glass, vase or chair leg) and then view several three-dimensional representations of it. These can be rotated to give a realistic impression of the finished object and the user can, on the basis of this, modify the original shape. In addition, when the design of the object is satisfactory, a model can be machined on a lathe (available separtely) which is operated automatically by the computer.



Platform : BBC Micro
Format : 5.25" Floppy Disk
Publisher : Five Ways Software
Authors : Tim Alsop
Date : Unknown
Product Code :

Other Software by Five Ways Software:

Item Manufacturer Platform Format Date
Weather Five Ways Software 380Z 5.25" Floppy Disk Unknown
Computer-aided Design Five Ways Software BBC Micro 5.25" Floppy Disk Unknown
Physiological Simulation Five Ways Software BBC Micro 5.25" Floppy Disk Unknown
Approximation, Estimation, and Standard From Five Ways Software BBC Micro 5.25" Floppy Disk Unknown
Longitudinal Waves Five Ways Software BBC Micro 5.25" Floppy Disk Unknown
Scales Five Ways Software BBC Micro 5.25" Floppy Disk Unknown
Scales Five Ways Software Apple II Disk 5.25 1982
Approximation, Estimation & Standard Form Five Ways Software RM 380Z 5.25" Floppy Disk 1982
380Z Scales Five Ways Software RM 380Z 5.25" Floppy Disk 1982
The Dudley Programs Five Ways Software BBC Micro 5.25" Floppy Disk 1983
Weather Five Ways Software BBC Micro 5.25" Floppy Disk 1983
Homes Five Ways Software BBC Micro 5.25" Floppy Disk 1983

Information About Five Ways Software:







This exhibit has a reference ID of CH21732. Please quote this reference ID in any communication with the Centre for Computing History. 		  Computer-aided Design Click on the Images
